293-51-450 (F0504 probe) Electronic multi-function micrometer

293-51-450 (F0504 probe) Electronic multi-function micrometer

$160.00
$160.00
Sale Sold out

SKU:

Free Shipping

Free standard shipping on orders over 9.00 $

Return Policy

Returns within 30 days of receiving the item, as long as products are in their original condition, unused, and in the original packaging. Refunds or exchanges are available once the return is processed, with some exceptions based on the item’s condition and category.

MORE
View full details

Description

Measurement parameters

Part Number Measuring range Accuracy C L
293-51-450 0-25mm ±0.002mm 26mm 42mm
293-52-450 25-50mm ±0.002mm 38mm 67mm
293-53-450 50-75mm ±0.003mm 50mm 92mm
293-54-450 75-100mm ±0.003mm 62mm 118mm
293-55-450 100-125mm ±0.003mm 70mm 143mm
293-56-450 125-150mm ±0.003mm 82mm 168mm
293-57-450 150-175mm ±0.004mm 95mm 192mm
293-58-450 175-200mm ±0.004mm 107mm 217mm

Dimensions

Enterprise WeChat screenshot_17046771563887

Measuring slot diameter

Page 31-113

Measuring the root dimensions of special-shaped parts

Page 31-114

Measuring the tap root size

Page 31-115

Measuring the gear normal

Page 31-116
